Mathematical modelling and experimental investigation of dehumidifier drying of radiata pine timber

Authors

  • Z. F. Sun University of Otago
  • C. G. Carrington University of Otago
  • C. Davis University of Otago
  • Q. Sun University of Otago
  • S. Pang University of Canterbury

Keywords:

characteristic drying curve, dehumidifier drying, kiln stack, mathematical model, pinus radiata, sapwood timber

Abstract

A dynamic kiln-wide wood drying model was developed previously to solve the integral form of the unsteady-state mass, momentum and energy balance equations in the air side. For the wood side, an empirical model, characteristic drying curve, for the internal moisture movement is used, which was obtained for low and medium temperature drying of Pinus radiata, with a medium velocity of 1.4- 4.1 m s–1. As part of the research programme to improve the design and control of dehumidifier wood drying kilns, the wood drying model has been assessed using the experimental data measured under drying conditions similar to those in dehumidifier kiln. It is noted that close agreement between the modelled results and the experimental data can be obtained for Pinus radiata drying processes with a medium air velocity (< 5 m s–1). However, larger discrepancy between the modelled results and the measured data has been observed with a higher velocity (8 m s–1). To solve this problem a new characteristic drying curve, based on a two-zone diffusion model, has been used in the kiln-wide wood drying model and more accurate results have been obtained.

Downloads

Download data is not yet available.

Author Biographies

Z. F. Sun, University of Otago

Physics Department, University of Otago,PO Box 56, Dunedin, New Zealand.

C. G. Carrington, University of Otago

Physics Department, University of Otago,PO Box 56, Dunedin, New Zealand.

C. Davis, University of Otago

Physics Department, University of Otago,PO Box 56, Dunedin, New Zealand.

Q. Sun, University of Otago

Physics Department, University of Otago,PO Box 56, Dunedin, New Zealand.

S. Pang, University of Canterbury

Department of Chemical and Process Engineering, University of Canterbury, Christchurch, New Zealand.

How to Cite

Sun, Z. F., Carrington, C. G., Davis, C., Sun, Q., & Pang, S. (2014). Mathematical modelling and experimental investigation of dehumidifier drying of radiata pine timber. Maderas. Ciencia Y Tecnología, 7(2), 87–98. Retrieved from https://revistas.ubiobio.cl/index.php/MCT/article/view/1468
