Laminated bamboo lumber beams: An evaluation of structural behavior and bonding quality
DOI:
https://doi.org/10.22320/s0718221x/2026.13Keywords:
Bonding performance, Dendrocalamus asper, finite element modeling, laminated bamboo lumber, Phyllostachys pubescens, structural analysisAbstract
Laminated bamboo lumber is a lignocellulosic composite with a wide range of applications in construction. Despite its growing use in structural applications, the structural behavior of laminated bamboo lumber has not been sufficiently investigated through advanced numerical modelling approaches, and the influence of species–adhesive combinations on bonding performance remains insufficiently understood. This lack of integrated numerical–experimental studies represents a critical research gap for the reliable structural analysis of bamboo-based elements. This work aimed to address this gap by numerically and experimentally evaluating laminated bamboo lumber elements submitted to three-point bending tests and by assessing the bonding performance of four distinct species-adhesive combinations (i.e. Dendrocalamus asper, Phyllostachys pubescens). The physical and mechanical properties of the lamellas were obtained from the experimental characterization of bamboo. A finite element modeling was developed to simulate the structural response, incorporating orthotropic behavior and physical non-linearity. The constitutive model adopted for bamboo followed Hill's criterion, simulating elastic-plastic behavior through bilinear curves. The numerical and experimental results showed good agreement, and the model was able to simulate the behavior of beams in bending, including the identification of critical stresses regions along the element. The species-adhesive combinations showed high delamination and shear strength at the glue lines. The results demonstrate the capability of the proposed numerical framework to predict the bending behavior of laminated bamboo lumber and highlight the importance of appropriate species–adhesive selection, contributing to the development of reliable design and manufacturing strategies for structural bamboo products.
Downloads
References
ANSYS. 2005. Student 10.0. ANSYS, Inc. https://www.ansys.com/it-solutions/platform-support/previous-releases
Alves, L.F.; Araujo, V.; Christoforo, A.L. 2025. Characterization of the structural engineered bamboo industry based on manufacturer web-prospecting. Discover Civil Engineering 2(1). e169. https://doi.org/10.1007/s44290-025-00330-9 DOI: https://doi.org/10.1007/s44290-025-00330-9
Araujo, V.; Mascarenhas, F.; Laleicke, F.; Kutnar, A.; Dias, A.; van de Kuilen, J.; Hubbe, M.; Lahr, F.; Christoforo, A. 2026. Biocities with wood and bamboo: a path to low-carbon urbanization for greener societies. Renewable and Sustainable Energy Reviews 226. e116257. https://doi.org/10.1016/j.rser.2025.116257 DOI: https://doi.org/10.1016/j.rser.2025.116257
Associação Brasileira de Normas Técnicas ABNT. 2022c. Projeto de estruturas de madeira. ABNT NBR 7190-1. ABNT. Rio de Janeiro, RJ, Brazil.
Associação Brasileira de Normas Técnicas ABNT. 2022b. Projeto de estruturas de madeira - Parte 3: Métodos de ensaio para corpos de prova isentos de defeitos para madeiras de florestas nativas. ABNT NBR 7190-3. ABNT. Rio de Janeiro, RJ, Brazil.
Associação Brasileira de Normas Técnicas. 2022a. Projeto de estruturas de madeira - Parte 6: Métodos de ensaio para caracterização de madeira lamelada colada estrutural. ABNT NBR 7190-6. ABNT. Rio de Janeiro, RJ, Brazil.
Associação Brasileira de Normas Técnicas. 2020. Estruturas de bambu Parte 2: Determinação das propriedades físicas e mecânicas do bambu. ABNT NBR 16828-2. ABNT. Rio de Janeiro, RJ, Brazil.
Beraldo, A.L.; Rivero, L.A. 2003. Glued Laminated Bamboo (GLB). Floram 10(2): 36-46.
Calil Neto, C.; Molina, J. C.; Calil Junior, C.; Lahar, F. A. R. 2017. Modelagem numérica do comportamento de ligações com parafusos auto-atarraxantes em X em corpos de prova de MLC com madeiras do tipo Eucalipto urograndis. Matéria (Rio de Janeiro), 22(1), e11789. https://doi.org/10.1590/s1517-707620170001.0121 DOI: https://doi.org/10.1590/s1517-707620170001.0121
Chen, F.; Wang, G.; Li, X.; Simth, L.M.; Shi, S.Q. 2016. Laminated structure design of wood-bamboo hybrid laminated composite using finite element simulations. Journal of Reinforced Plastics and Composites 35(22): 1661-1670. https://doi.org/10.1177/0731684416663852 DOI: https://doi.org/10.1177/0731684416663852
Correal D., J.F.; Arbeláez C.J. 2010. Influence of age and height position on colombian Guadua angustifolia bamboo mechanical properties. Maderas. Ciencia y Tecnología 12(2): 105-114. https://doi.org/10.4067/s0718-221x2010000200005 DOI: https://doi.org/10.4067/S0718-221X2010000200005
Fu, Y.; Fang, H.; Dai, F. 2017. Study on the properties of the recombinant bamboo by finite element method. Composites Part B: Engineering 115: 151-159. https://doi.org/10.1016/j.compositesb.2016.10.022 DOI: https://doi.org/10.1016/j.compositesb.2016.10.022
Ghavami, K.; Marinho, A.B. 2005. Physical and mechanical properties of the whole culm of bamboo of the Guadua angustifolia species. Revista Brasileira de Engenharia Agrícola e Ambiental 9(1): 107-114. https://doi.org/10.1590/s1415-43662005000100016 DOI: https://doi.org/10.1590/S1415-43662005000100016
Hu, W.; Chen, B.; Lin, X.; Guan, H. 2021. Experimental and numerical study on a novel bamboo joint for furniture considering effect of loading type on mechanical parameters used in finite element method. Maderas. Ciencia y Tecnología 23(62): 1-14. https://doi.org/10.4067/s0718-221x2021000100462 DOI: https://doi.org/10.4067/S0718-221X2021000100462
Khatib, A.; Nounu, G. 2017. Corrugated bamboo as reinforcement in concrete. Proceedings of the Institution of Civil Engineers - Structures and Buildings 170(4): 311-318. https://doi.org/10.1680/jstbu.16.00067 DOI: https://doi.org/10.1680/jstbu.16.00067
Kingsley, U.; Imoisili, P.E.; Adgidzi, D. 2015. Finite Element Analysis of Bamboo Bicycle Frame. Journal of Advances in Mathematics and Computer Science 5(5): 583-594. https://doi.org/10.9734/bjmcs/2015/13451 DOI: https://doi.org/10.9734/BJMCS/2015/13451
Lapo, L. E. R., & Beraldo, A. L. 2008. Bambu Laminado Colado (BLC). Revista Em Agronegócio E Meio Ambiente, 1(2), 165–177. https://doi.org/10.17765/2176-9168.2008v1n2p165-177
Lefevre, B.; West, R.; O'Reilly, P.; Taylor, D. 2019. A new method for joining bamboo culms. Engineering Structures 190: 1-8. https://doi.org/10.1016/j.engstruct.2019.04.003 DOI: https://doi.org/10.1016/j.engstruct.2019.04.003
Li, H.-T.; Su, J.-W.; Zhang, Q.-S.; Deeks, A.J.; Hui, D. 2015. Mechanical performance of laminated bamboo column under axial compression. Composites Part B: Engineering 79: 374-382. https://doi.org/10.1016/j.compositesb.2015.04.027 DOI: https://doi.org/10.1016/j.compositesb.2015.04.027
Lima, D.M.; Amorim, M.M.; Lima Júnior, H.C.; Barbosa, N.P.; Wilrich, F.L. 2014. Avaliação do comportamento de vigas de bambu laminado colado submetidas à flexão. Ambiente Construído 14(1): 15-27. https://doi.org/10.1590/s1678-86212014000100003 DOI: https://doi.org/10.1590/S1678-86212014000100003
Liu, K.; Jayaraman, D.; Shi, Y.; Xiong, Z.; Yang, J.; Symeonidis, A.; Zea Escamilla, E. 2024. Life cycle assessment (LCA) of the industrial production of structural glued laminated bamboo. Journal of Cleaner Production 485. e144367. https://doi.org/10.1016/j.jclepro.2024.144367 DOI: https://doi.org/10.1016/j.jclepro.2024.144367
Luna, P.; Lozano, J.; Takeuchi, C. 2014. Determinación experimental de valores característicos de resistencia para Guadua angustifolia. Maderas. Ciencia y Tecnología 16(1): 77-92. https://doi.org/10.4067/s0718-221x2014005000007 DOI: https://doi.org/10.4067/s0718-221x2014005000007
Molina, J.C. 2008. Análise do comportamento dinâmico da ligação formada por barras de aço coladas para tabuleiros mistos de madeira e concreto para pontes. PhD dissertation, São Paulo University, São Carlos, Brazil.
Nogueira, C.L. 2008. Painel de bambu laminado colado estrutural. Master thesis, São Paulo University, Piracicaba, Brazil.
Ogunsanwo, O.Y.; Adenaiya, A.O.; Adedeji, C.A. 2019. Effect of adhesive quantity on selected physico-mechanical properties of bamboo glulam. Maderas. Ciencia y Tecnología 21(1): 113-122. https://doi.org/10.4067/s0718-221x2019005000111 DOI: https://doi.org/10.4067/S0718-221X2019005000111
Paes, J.B.; Oliveira, A.K.F.; Oliveira, E.; Lima, C.R. 2009. Physical-mechanical characterization of the glue laminated bamboo (Dendrocalamus giganteus). Ciência Florestal 19(1): 41-51. https://doi.org/10.5902/19805098418 DOI: https://doi.org/10.5902/19805098418
Rosa, R.A.; Paes, J.B.; Segundinho, P.G.A.; Vidaurre, G.B.; Oliveira, A.K.F. 2016. Influences of species, preservative treatment and adhesives on physical properties of laminated bamboo lumber. Ciência Florestal 26(3): 913-924. https://doi.org/10.5902/1980509824220 DOI: https://doi.org/10.5902/1980509824220
Santos, T.O. 2019. Produção de bambu laminado colado: propriedades e aplicações. Master thesis, São Carlos Federal University, Sorocaba, Brazil.
Sharma, B.; Bauer, H.; Schickhofer, G.; Ramage, M.H. 2017. Mechanical characterisation of structural laminated bamboo. Proceedings of the Institution of Civil Engineers - Structures and Buildings 170(4): 250-264. https://doi.org/10.1680/jstbu.16.00061 DOI: https://doi.org/10.1680/jstbu.16.00061
Zhu, Y.; Xu, M.; Cui, Z.; Ou, J.; Zhu, J. 2026. Experimental and numerical investigation on fire resistance of laminated bamboo lumber beams under standard fire exposure. Journal of Building Engineering 118. e115010. https://doi.org/10.1016/j.jobe.2025.115010 DOI: https://doi.org/10.1016/j.jobe.2025.115010
